Copper Pipes and Tubes Manufacturer and Exporter in Sudan

October 8, 2026
Copper Pipes, Copper Tube

Manibhadra Fitting is a trusted manufacturer and exporter of top quality Copper Pipes and Tubes in Sudan. We provide medical gas, plumbing, HVAC, refrigeration and industrial seamless copper pipes. We use high quality and purity material copper in our production, and our products meet international quality standards. We provide trustworthy piping solutions with an excellent corrosion resistance, durability, and a long service life.

Copper Pipes and Tubes Manufacturer and Exporter in Sudan

Copper Pipes and Tubes Types in Sudan

Manibhadra Fitting is a one-stop solution for all Copper Pipes and Tubes required for various industries and applications. We make products with accurate size, smooth inner surface and good pressure resistance to ensure good performance.

Medical Gas Copper Pipes and Tubes in Sudan

The Medical Gas Copper Pipes and Tubes are designed specifically for medical environments, such as hospitals, healthcare facilities, and laboratories, where the reliable and contamination-free delivery of medical gases is critical. To ensure maximum cleanliness, all pipes are cleaned, degreased and capped before packing. These pipes can be used in medical gas pipeline, vacuum and medical air, oxygen, and nitrous oxide applications.

Medical Copper Pipes and Tubes Manufacturer and Exporter in South Africa

Plumbing Copper Pipes and Tubes in Sudan

Manibhadra Fitting is a manufacturer of Plumbing Copper Pipes and Tubes that are used in residential, commercial, and industrial water distribution systems. Copper is commonly used due to its corrosion-resistant, hygienic and long-term service capabilities. We do not leak and our plumbing service lines need very little maintenance over the years.

AC and Refrigeration Copper Pipes and Tubes in Sudan

Our AC and Refrigeration Copper Pipes are used for air conditioning, refrigeration and HVAC applications. The pipes are made of a material that has high thermal conductivity and is highly resistant to pressure, which ensures the efficient flow of refrigerant and enhanced cooling performance. They come in straight lengths, coils for various installation needs.

Copper Pipes And Tubes Chemical Composition

Manibhadra Fitting produces Copper Pipes and Tubes from a high purity copper so as to achieve the best mechanical strength and corrosion resistance. The controlled chemical composition results in high ductility, high thermal conductivity and good long term performance in challenging industrial applications. All products are made following international quality standards to ensure reliability.

Medical Gas Copper Pipe & Tube Chemical Composition

Element	Composition
Copper (Cu)	≥ 99.90%
Phosphorus (P)	0.015% – 0.040%

Plumbing Copper Pipe & Tube Chemical Composition

Element	Composition
Copper (Cu + Ag)	≥ 99.90%
Phosphorus (P)	0.015% – 0.040%

AC & Refrigeration Copper Pipe & Tubes Chemical Composition

UNS C10200 (Oxygen-Free Copper)

Element	Composition
Copper (Cu + Ag)	≥ 99.95%
Oxygen (O)	≤ 10 ppm

UNS C12200 (DHP Copper)

Element	Composition
Copper (Cu + Ag)	≥ 99.90%
Phosphorus (P)	0.015% – 0.040%

Copper Pipes and Tubes Weight, Size and Dimension Tables

Manibhadra Fitting has a manufacturing facility of Copper Pipes and Tubes in different sizes, wall thickness and length as per different industrial requirements. Pipes are manufactured with close dimensional tolerances for ease of installation and satisfactory performance. Available in standard and custom sizes according to customer needs and specifications.

Medical Gas Copper Pipes and Tubes Weight, Size and Dimension Tables

We supply Medical Gas Copper Pipes in different diameters and wall thickness for healthcare infrastructure projects. All pipes are made to international medical gas standard, which guarantees them to have precise dimensions and excellent cleanliness and reliability in medical gas distribution.

EN 13348 Medical Gas Copper Pipes and Tubes Weight, Size and Dimension Tables

Nominal Outside Diameter (mm)	Tube Length (m)	Wall Thickness (mm)
12	6	0.6
15	3, 6	0.7
22	3, 6	0.9
28	3, 6	0.9
35	6	1.0
42	6	1.0
54	6	1.0
67	6	1.5
76	6	1.5
108	6	1.5
133	6	1.5
159	6	2.0
219	6	3.0

Type K ASTM B819 Medical Gas Copper Pipes and Tubes Weight, Size and Dimension Tables

Nominal Size	Outside Diameter (in)	Inside Diameter (in)	Wall Thickness (in)	Internal Volume of Tube (ft³/ft)
1/4	0.375	0.305	0.035	0.00051
3/8	0.500	0.402	0.049	0.00088
1/2	0.625	0.527	0.049	0.00151
5/8	0.750	0.652	0.049	0.00232
3/4	0.875	0.745	0.065	0.00303
1	1.125	0.995	0.065	0.00540
1 1/4	1.375	1.245	0.065	0.00845
1 1/2	1.625	1.481	0.072	0.0120
2	2.125	1.959	0.083	0.0209
2 1/2	2.625	2.435	0.095	0.0323
3	3.125	2.907	0.109	0.0461
4	4.125	3.857	0.134	0.0811
5	5.125	4.805	0.160	0.126
6	6.125	5.741	0.192	0.180
8	8.125	7.583	0.271	0.314

Type L ASTM B819 Medical Gas Copper Pipes and Tubes Weight, Size and Dimension Tables

Nominal Size	Outside Diameter (in)	Inside Diameter (in)	Wall Thickness (in)	Internal Volume of Tube (ft³/ft)
1/4	0.375	0.315	0.030	0.00054
3/8	0.500	0.430	0.035	0.00101
1/2	0.625	0.545	0.040	0.00162
5/8	0.750	0.666	0.042	0.00242
3/4	0.875	0.785	0.045	0.00336
1	1.125	1.025	0.050	0.00573
1 1/4	1.375	1.265	0.055	0.00873
1 1/2	1.625	1.505	0.060	0.0124
2	2.125	1.985	0.070	0.0215
2 1/2	2.625	2.465	0.080	0.0331
3	3.125	2.945	0.090	0.0473
4	4.125	3.905	0.110	0.0832
5	5.125	4.875	0.125	0.130
6	6.125	5.854	0.140	0.186
8	8.125	7.725	0.200	0.325

Plumbing Copper Pipes and Tubes Weight, Size and Dimension Tables

Plumbing Copper Pipes are available in various sizes for a range of applications including residential, commercial and industrial plumbing. Stable dimensional accuracy, the pipes can be used for hot water, cold water and drinking water.

EN 1057 Copper Plumbing Pipes and Tubes Weight, Size and Dimension Tables

Nominal Outside Diameter (mm)	Tube Length (m)	Wall Thickness (mm)
Nominal Outside Diameter (mm)	Tube Length (m)	X	Y
6	3, 6	0.6	0.8
8	3, 6	0.6	0.8
10	3, 6	0.6	0.8
15	3, 6	0.7	1.0
22	3, 6	0.9	1.2
28	3, 6	0.9	1.2
35	3, 6	1.2	1.5
42	3, 6	1.2	1.5
54	3, 6	1.2	2.0
67	3, 6	1.2	2.0
76	3, 6	1.5	2.0
108	3, 6	1.5	2.5
133	3, 6	1.5
159	3, 6	2.0
219	6	3.0

Type K ASTM B88 Copper Plumbing Pipes and Tubes Weight, Size and Dimension Tables

Nominal Size (inches)	Actual Outside Diameter			Tolerance on Outside Diameter				Wall Thickness				Weight
	Actual Outside Diameter			Annealed		Drawn		Nominal		Tolerance		Weight
	(inches)		(mm)	(inches)	(mm)	(inches)	(mm)	(inches)	(mm)	(inches)	(mm)	(lb/ft)	(Kg/m)
1/4	3/8	0.375	9.52	0.002	0.0508	0.001	0.0254	0.035	0.889	0.0035	0.0889	0.133	0.20
3/8	1/2	0.5	12.7	0.0025	0.0635	0.001	0.0254	0.049	1.24	0.005	0.127	0.269	0.40
1/2	5/8	0.625	15.9	0.0025	0.0635	0.001	0.0254	0.049	1.24	0.005	0.127	0.344	0.51
5/8	3/4	0.75	19	0.0025	0.0635	0.001	0.0254	0.049	1.24	0.005	0.127	0.418	0.62
3/4	7/8	0.875	22.2	0.003	0.0762	0.001	0.0254	0.065	1.65	0.006	0.152	0.641	0.95
1	1 1/8	1.125	28.6	0.0035	0.0889	0.0015	0.0381	0.065	1.65	0.006	0.152	0.837	1.25
1 1/4	1 3/8	1.375	34.9	0.004	0.102	0.0015	0.0381	0.065	1.65	0.006	0.152	1.04	1.55
1 1/2	1 5/8	1.625	41.3	0.0045	0.114	0.002	0.0508	0.072	1.83	0.007	0.178	1.36	2.02
2	2 1/8	2.125	54	0.005	0.127	0.002	0.0508	0.083	2.11	0.008	0.203	2.06	3.07
2 1/2	2 5/8	2.625	66.7	0.005	0.127	0.002	0.0508	0.095	2.41	0.01	0.254	2.92	4.35
3	3 1/8	3.125	79.4	0.005	0.127	0.002	0.0508	0.109	2.77	0.011	0.279	4	5.95
3 1/2	3 5/8	3.625	92.1	0.005	0.127	0.002	0.0508	0.12	3.05	0.012	0.305	5.12	7.62
4	4 1/8	4.125	105	0.005	0.127	0.002	0.0508	0.134	3.4	0.013	0.33	6.51	9.69
5	5 1/8	5.125	130	0.005	0.127	0.002	0.0508	0.16	4.06	0.016	0.406	9.67	14.39
6	6 1/8	6.125	156	0.005	0.127	0.002	0.0508	0.192	4.88	0.019	0.483	13.87	20.64

Type L ASTM B88 Copper Plumbing Pipes and Tubes Weight, Size and Dimension Tables

Nominal Size	Actual Outside Diameter			Weight		Tolerance on Outside Diameter				Wall Thickness
Nominal Size	Actual Outside Diameter			Weight		Annealed		Drawn		Nominal		Tolerance
(inches)	(inches)	(inches)	(mm)	(lb/ft)	(kg/m)	(inches)	(mm)	(inches)	(mm)	(inches)	(mm)	(inches)	(mm)
1/4	3/8	0.375	9.52	0.126	0.187	0.002	0.0508	0.001	0.0254	0.03	0.762	0.003	0.0762
3/8	1/2	0.5	12.7	0.198	0.286	0.0025	0.0635	0.001	0.0254	0.035	0.889	0.004	0.102
1/2	5/8	0.625	15.9	0.285	0.424	0.0025	0.0635	0.001	0.0254	0.04	1.02	0.004	0.102
5/8	3/4	0.75	19	0.362	0.539	0.0025	0.0635	0.001	0.0254	0.042	1.07	0.004	0.102
3/4	7/8	0.875	22.2	0.455	0.678	0.003	0.0762	0.001	0.0254	0.045	1.14	0.004	0.102
1	1 1/8	1.125	28.6	0.655	0.974	0.0035	0.0889	0.0015	0.0381	0.05	1.27	0.005	0.127
1 1/4	1 3/8	1.375	34.9	0.884	1.315	0.004	0.102	0.0015	0.0381	0.055	1.4	0.006	0.152
1 1/2	1 5/8	1.625	41.3	1.14	1.697	0.0045	0.114	0.002	0.0508	0.06	1.52	0.006	0.152
2	2 1/8	2.125	54	1.75	2.602	0.005	0.127	0.002	0.0508	0.07	1.78	0.007	0.178
2 1/2	2 5/8	2.625	66.7	2.48	3.687	0.005	0.127	0.002	0.0508	0.08	2.03	0.008	0.203
3	3 1/8	3.125	79.4	3.33	4.954	0.005	0.127	0.002	0.0508	0.09	2.29	0.009	0.229
3 1/2	3 5/8	3.625	92.1	4.29	6.381	0.005	0.127	0.002	0.0508	0.1	2.54	0.01	0.254
4	4 1/8	4.125	105	5.38	8.007	0.005	0.127	0.002	0.0508	0.114	2.9	0.011	0.279
5	5 1/8	5.125	130	7.61	11.33	0.005	0.127	0.002	0.0508	0.125	3.18	0.012	0.305
6	6 1/8	6.125	156	10.2	15.18	0.005	0.127	0.002	0.0508	0.14	3.56	0.014	0.356

Type M ASTM B88 Copper Plumbing Pipes and Tubes Weight, Size and Dimension Tables

Nominal Size	Actual Outside Diameter			Tolerance on Outside Diameter				Wall Thickness				Weight
Nominal Size	Actual Outside Diameter			Annealed		Drawn		Nominal		Tolerance		Weight
(inches)	(inches)	(inches)	(mm)	(inches)	(mm)	(inches)	(mm)	(inches)	(mm)	(inches)	(mm)	(lb/ft)	(mm)
1/4	3/8	0.375	9.52	0.002	0.0508	0.001	0.0254	–	–	–	–	0.106	0.158
3/8	1/2	0.5	12.7	0.0025	0.0635	0.001	0.0254	0.025	0.64	0.002	0.0508	0.144	0.214
1/2	5/8	0.625	15.9	0.0025	0.0635	0.001	0.0254	0.028	0.71	0.003	0.0762	0.203	0.302
5/8	3/4	0.75	19	0.0025	0.0635	0.001	0.0254	–	–	–	–	0.263	0.391
3/4	7/8	0.875	22.2	0.003	0.0762	0.001	0.0254	0.032	0.81	0.003	0.0762	0.328	0.488
1	1 1/8	1.125	28.6	0.0035	0.0889	0.0015	0.0381	0.035	0.89	0.004	0.102	0.464	0.691
1 1/4	1 3/8	1.375	34.9	0.004	0.102	0.0015	0.0381	0.042	1.07	0.004	0.102	0.681	1.013
1 1/2	1 5/8	1.625	41.3	0.0045	0.114	0.002	0.0508	0.049	1.24	0.005	0.127	0.94	1.399
2	2 1/8	2.125	54	0.005	0.127	0.002	0.0508	0.058	1.47	0.006	0.152	1.46	2.173
2 1/2	2 5/8	2.625	66.7	0.005	0.127	0.002	0.0508	0.065	1.65	0.006	0.152	2.03	3.021
3	3 1/8	3.125	79.4	0.005	0.127	0.002	0.0508	0.072	1.83	0.007	0.178	2.68	3.988
3 1/2	3 5/8	3.625	92.1	0.005	0.127	0.002	0.0508	0.083	2.11	0.008	0.203	3.58	5.328
4	4 1/8	4.125	105	0.005	0.127	0.002	0.0508	0.095	2.41	0.01	0.254	4.66	6.935
5	5 1/8	5.125	130	0.005	0.127	0.002	0.0508	0.109	2.77	0.011	0.279	6.66	9.911
6	6 1/8	6.125	156	0.005	0.127	0.002	0.0508	0.122	3.10	0.012	0.305	8.91	13.260

AC and Refrigeration Copper Pipes and Tubes Weight, Size and Dimension Tables

Our AC and Refrigeration Copper Pipes come in different diameters and thicknesses to suit the contemporary HVAC and refrigeration systems. Precisely made, they offer uninterrupted refrigerant flow, simplified brazing and long-term durability in both residential and commercial cooling applications.

ASTM B289 AC and Refrigeration Copper Pipes and Tubes Weight, Size and Dimension Tables

Nominal Size (inches)	Annealed (A) or Drawn Temper (D)	Outside Diameter (inches)	Inside Diameter (inches)	Wall Thickness (inches)	Cross Sectional Area of Bore (square inches)
1/8	A	0.125 3.18	0.065 1.65	0.030 0.762	0.0033
3/16	A	0.187 4.75	0.128 3.25	0.030 0.762	0.0129
1/4	A	0.250 6.35	0.190 4.83	0.030 0.762	0.0284
5/16	A	0.312 7.92	0.248 6.3	0.032 0.813	0.0483
3/8	A	0.375 9.52	0.311 7.9	0.032 0.813	0.076
3/8	D	0.375 9.52	0.315 8	0.030 0.762	0.078
1/2	A	0.500 12.7	0.436 11.1	0.032 0.813	0.149
1/2	D	0.500 12.7	0.430 10.9	0.035 0.889	0.145
5/8	A	0.625 15.9	0.555 14.1	0.035 0.889	0.242
5/8	D	0.625 15.9	0.545 13.8	0.040 1.02	0.233
3/4	A	0.750 19	0.680 17.3	0.035 0.889	0.363
	A	0.750 19	0.666 16.9	0.042 1.07	0.348
	D	0.750 19	0.666 16.9	0.042 1.07	0.348
7/8	A	0.875 22.2	0.785 19.9	0.045 1.14	0.484
7/8	D	0.875 22.2	0.785 19.9	0.045 1.14	0.484
1 1/8	A	1.125 28.6	1.025 26	0.050 1.27	0.825
1 1/8	D	1.125 28.6	1.025 26	0.050 1.27	0.825
1 3/8	A	1.375 34.9	1.265 32.1	0.055 1.4	1.26
1 3/8	D	1.375 34.9	1.265 32.1	0.055 1.4	1.26
