Manibhadra Fitting has a variety of coppers in the UK, and the copper flanges are designed to perform in diverse industrial requirements precisely and strongly. Different copper flanges have different functions and provide secure connections guaranteeing efficient running of the system. Manibhadra Fitting and Production using: Manibhadra fitting guarantees that more of the flanges are produced by the high grade copper material and high production techniques. Manibhadra fitting provides copper flanges that can fit in an area with high pressure, high temperature, and corrosive environments. With the reputation of being a reputed copper flanges exporter in the UK, Manibhadra Fitting provides tailor-made copper flanges to suit different application requirements.
Copper Flanges Manufacturer, Stockist, and Exporter in UK : Types
Manibhadra Fitting has a variety of coppers in the UK, and the copper flanges are designed to perform in diverse industrial requirements precisely and strongly. Different copper flanges have different functions and provide secure connections guaranteeing efficient running of the system. Manibhadra Fitting and Production using: Manibhadra fitting guarantees that more of the flanges are produced by the high grade copper material and high production techniques. Manibhadra fitting provides copper flanges that can fit in an area with high pressure, high temperature, and corrosive environments. With the reputation of being a reputed copper flanges exporter in the UK, Manibhadra Fitting provides tailor-made copper flanges to suit different application requirements.
Copper Weld Neck Flanges in UK
Copper Weld Neck flanges provided by Manibhadra Fitting in UK are characterized by longer tapered hub and good distribution of stresses. The high-pressure application is where they are perfect, cases that have to be bent, and cases where there are temperature changes. Manibhadra Fitting delivers high strength leak proof connections with every weld neck flange. They are common in chemical factories, power station, and also in shipyards.
Copper Slip-On Flanges in UK
Manibhadra Fitting is a producer of slip on copper flanges, which are aligned easily and are simple to fit. Such flanges are used in low pressure systems and when piping is not fatal. Manibhadra Fitting also distributes these flanges in the UK to the HVAC, water treatment and food units. Their smooth internal bore allows flow of fluid in the system easily and minimizing turbulence within the system.
Copper Threaded Flanges in UK
Manibhadra Fitting provide copper threaded flanges which can be used in the fields where welding is not a good option or not possible at all. They are flanges, which have internal threads and they are most appropriate in small diameter and low pressure piping systems. Threaded flanges manufactured by Manibhadra Fitting is also used in flammable gas industries or hazardous liquids industries to keep them safe in the UK.
Copper Socket-Weld Flanges in UK
Manibhadra Fitting has copper socket-weld flanges that are designed on small-bore piping systems used in high-pressure applications. These flanges are very strong against fatigue and have good-flow properties because of smooth-bore. All products of socket-weld flange delivered throughout the UK have the guarantee of tight tolerance and dimensional correctness provided by Manibhadra Fitting company.
Copper Blind Flanges in UK
Manibhadra Fitting is a firm dealing in copper blind flanges in UK to successfully seal off the ends of piping systems. Such flanges are applied in system pressure tests or where extension of the system is envisaged in future. Manibhadra Fitting blind flanges have a great resistance to corrosion and are durable, thus meet the requirements of petrochemical, marine and water treatment plants.
Copper Orifice Flanges in UK
Manibhadra Fitting is a copper orifice flange manufacturer meant to determine the rate of flow in pipes. These flanges feature pressure taps on either side of it to allow correct readings of the differential pressure. Manibhadra Fitting offers orifice flanges to oil & gas, chemical and energy industries to monitor and control the procedures in the UK.
Copper Flanges in UK : Properties
Manibhadra Fitting is a dealer of copper flanges in the UK, which are famous around the world due to their great mechanical and physical characteristics that make them suitable in high-importance and complex applications. The design of these flanges is to work in harsh environments, which is possible through their high thermal conductivity, resistance to corrosions, as well as strength. Manibhadra Fitting has quality products due to the manufacturing of every copper flange to meet fierce UK and global quality standards.
These flanges are perfect in the marine, chemical, plumbing, and HVAC sectors owing to their high construction standards and extended life span. The copper flanges of Manibhadra Fitting are performed consistently in the UK where reliability and compliance play a key role. They are able to fit various industrial systems and operating conditions due to their flexibility.
- High Corrosion resistance
Manibhadra Fitting and copper flanges are extremely rust resistant, this makes them ideal in coastal and industrial areas in the UK. The sustainability of this property is longer life span and lower maintenance cost. Copper is already non-oxidative especially in moisture-prone or chemically active areas. This is particularly relevant when its use is in plumbing and marine installations. - Best Thermal conductivity
Copper flanges made by Manibhadra Fitting is highly conductive thermally and this highlights why it is ideal when used in heat exchange systems as well as HVAC processes. This implies effective temperature control in the diverse climatic conditions in the UK. These flanges promote energy efficiency through fast transmission of heat that is needed in systems of industrial heat and cooling procedures. - Strong Mechanical Strength
The copper flanges supplied by Manibhadra Fitting are highly mechanically tough and do the job in a high-pressure environment. This guarantees structural integrity in piping systems, even when the pipes are on constant stress or vibration. They are designed with sturdy structure thus resistant to defunding and leakages in harsh UK industrial environments. - Fine machinability and weldability Easy
Copper flanges can be readily machined and welded together as well as be flexibly installed and fitted. Manibhadra Fitting comfortably maintains these properties in order to be easily incorporated in any form of project during the manufacturing process. This strength comes in handy the most in the United Kingdom construction and infrastructure sectors, where fast and safe connectivity are more critical than anything. - Temp and Pressure resistance
Manibhadra Fitting uses copper flanges to cope with extreme pressures and temperature ranges, which makes those flanges to be used in critical systems. This is why they prove to be reliable as they are used in the UK HVAC systems, power plants and process industries. The value of long-term system stability derives because of their reliability under harsh conditions. - Eco Friendly and Recyclable
Flanges made out of copper can be completely recycled which makes Manibhadra Fitting flanges a green product which can be utilized by the industries in the UK that attach importance to recyclable solutions. It also has one less impact on the environment since it is recyclable without affecting its performance. The copper flanges supplied by the company aid the green building and responsible sourcing of materials.
Copper Flanges Specification Table
Manibhadra Fitting provides copper flanges in different specifications, various sizes and grades to support the various industrial demands present in the UK market. These are made to specifications of ASTM, EN and other global parameters. Several grade modifications are available such that customers can order flanges suited to a particular use requiring pressure, corrosive, or high temperatures. Compatibility is also presented in plumbing, HVAC, marine, and industrial piping systems due to a wide giving range.
| Parameter / Property | Details |
|---|---|
| Material | Copper, Copper Alloys (C11000, C12200, etc.) |
| Size Range | ½ inch to 24 inches (Custom sizes available) |
| Type | Slip-On, Weld Neck, Blind, Threaded, Lap Joint, etc. |
| Standard | ASME B16.5, ASTM B62/B152, EN 1092, DIN, etc. |
| Pressure Rating | Class 150, Class 300, Class 600, and higher |
| Temperature Range | Up to 400°F (204°C) (Varies based on alloy) |
| Face Type | Raised Face (RF), Flat Face (FF), Ring Type Joint (RTJ) |
| Material Composition | 99.9% Pure Copper (C11000) or Copper Alloys (C12200) |
| Tensile Strength | 210-250 MPa (Varies by grade and alloy) |
| Yield Strength | 33-70 MPa (Varies by grade and alloy) |
| Density | 8.94 g/cm³ |
| Thermal Conductivity | 390-400 W/m·K |
| Electrical Conductivity | 97-101% IACS |
| Corrosion Resistance | Excellent resistance to water, steam, and mild acids |
| Ductility | Highly ductile, easy to form and fabricate |
| Weldability | Excellent weldability with standard methods |
| Finish | Smooth, Serrated, or Custom as per requirement |
| Applications | Plumbing, HVAC, Medical Gas Systems, Industrial Piping |
| Customization | Available in sizes, coatings, and special designs |
Copper Flanges Manufacturer, Stockist and Supplier in UK :- Size, Weight, and Dimensions Table
Manibhadra Fitting stocks copper flanges available in large varieties of size, weights and dimensional values to meet the different project needs within UK. Its compatibility is also made possible by the availability of small to large-diameter flanges in case of both the light-duty and heavy-duty applications. With the smallest sizes in residential plumbing, such as compact systems, and larger sizes such as industrial pipelines, the wide size range facilitates design as well as installation flexibility. Efforts are made to dimension exactly each flange with the demand requirements of certain operational loads, making a perfect fit and assuring a good sealing performance.
| Nominal Size | Outside Diameter | Min. Thickness | RF Dia. | No. of Bolt Holes | Diameter of Holes | Bolt Circle | SO Bore ID | WN Bore ID | Dia. Hub Base | Dia. of Hub Top | SO LTH | WN LTH |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (OD) | (T) | (R) | (BC) | (SB) | (WB) | (HB) | (HT) | (SL) | (WL) | |||
| 1⁄2 | 3.5 | 0.38 | 1.38 | 4 | 0.62 | 2.38 | 0.88 | 0.62 | 1.19 | 0.84 | 0.56 | 1.81 |
| 3⁄4 | 3.88 | 0.44 | 1.69 | 4 | 0.62 | 2.75 | 1.09 | 0.82 | 1.5 | 1.05 | 0.56 | 2 |
| 1 | 4.25 | 0.5 | 2 | 4 | 0.62 | 3.12 | 1.36 | 1.05 | 1.94 | 1.32 | 0.62 | 2.12 |
| 11⁄4 | 4.62 | 0.56 | 2.5 | 4 | 0.62 | 3.5 | 1.7 | 1.38 | 2.31 | 1.66 | 0.75 | 2.19 |
| 11⁄2 | 5 | 0.62 | 2.88 | 4 | 0.62 | 3.88 | 1.95 | 1.61 | 2.56 | 1.9 | 0.81 | 2.38 |
| 2 | 6 | 0.69 | 3.62 | 4 | 0.75 | 4.75 | 2.44 | 2.07 | 3.06 | 2.38 | 0.94 | 2.44 |
| 21⁄2 | 7 | 0.81 | 4.12 | 4 | 0.75 | 5.5 | 2.94 | 2.47 | 3.56 | 2.88 | 1.06 | 2.69 |
| 3 | 7.5 | 0.88 | 5 | 4 | 0.75 | 6 | 3.57 | 3.07 | 4.25 | 3.5 | 1.12 | 2.69 |
| 31⁄2 | 8.5 | 0.88 | 5.5 | 8 | 0.75 | 7 | 4.07 | 3.55 | 4.81 | 4 | 1.19 | 2.75 |
| 4 | 9 | 0.88 | 6.19 | 8 | 0.75 | 7.5 | 4.57 | 4.03 | 5.31 | 4.5 | 1.25 | 2.94 |
| 5 | 10 | 0.88 | 7.31 | 8 | 0.88 | 8.5 | 5.66 | 5.05 | 6.44 | 5.56 | 1.38 | 3.44 |
| 6 | 11 | 0.94 | 8.5 | 8 | 0.88 | 9.5 | 6.72 | 6.07 | 7.56 | 6.63 | 1.5 | 3.44 |
| 8 | 13.5 | 1.06 | 10.62 | 8 | 0.88 | 11.75 | 8.72 | 7.98 | 9.69 | 8.63 | 1.69 | 3.94 |
| 10 | 16 | 1.12 | 12.75 | 12 | 1 | 14.25 | 10.88 | 10.02 | 12 | 10.75 | 1.88 | 3.94 |
| 12 | 19 | 1.19 | 15 | 12 | 1 | 17 | 12.88 | 12 | 14.38 | 12.75 | 2.12 | 4.44 |
| 14 | 21 | 1.31 | 16.25 | 12 | 1.12 | 18.75 | 14.14 | 13.25 | 15.75 | 14 | 2.19 | 4.94 |
| 16 | 23.5 | 1.38 | 18.5 | 16 | 1.12 | 21.25 | 16.16 | 15.25 | 18 | 16 | 2.44 | 4.94 |
| 18 | 25 | 1.5 | 21 | 16 | 1.25 | 22.75 | 18.18 | 17.25 | 19.88 | 18 | 2.62 | 5.44 |
| 20 | 27.5 | 1.62 | 23 | 20 | 1.25 | 25 | 20.2 | 19.25 | 22 | 20 | 2.81 | 5.62 |
| 22 | 29.5 | 1.75 | 25.25 | 20 | 1.38 | 27.25 | 22.22 | 21.25 | 24.25 | 22 | 3.07 | 5.82 |
| 24 | 32 | 1.81 | 27.25 | 20 | 1.38 | 29.5 | 24.25 | 23.25 | 26.12 | 24 | 3.19 | 5.94 |
Copper Flanges Manufacturer, Stockist and Supplier in UK :- Applications
Copper flanges produced and distributed by Manibhadra Fitting are significant in many different uses in various UK industrial and general industries. These items are principal in making leak proof connections, reliability in systems and durability. Manibhadra Fitting in the copper flange is used in the chemical plant, HVAC systems, power station, and marine systems in the industrial sector. In the meantime, in the general application they find wide usage in residential plumbing, and heating system and in their development of infrastructure. In the UK, copper flanges are invaluable in most of the operations because of their versatility and high performance.
Industrial Applications in UK :
- HVAC Systems
Copper flanges produce by Manibhadra Fitting are many times applied in heating, ventilation and air conditioning systems to make secure connections of pipes free of leakages. The systems have an advantage of copper resistance to thermal conductivity and corrosion. - Chemical Processing Faculty
Copper flanges in the chemical business in the UK are utilized in the transfer of corrosive fluids and gases. Manibhadra Fitting designs tough flanges, which can survive a hostile environment and be exposed to chemicals. - Generation Power Plants
Manibhadra Fitting supplies copper flanges in turbines and boilers where tolerance of heat and pressure is necessary. They make thermal and nuclear power plants safe. - Oil and Gas Business
The company sources exports that comprise of copper flanges dealing with the oil and gas industry in UK, both high pressure flanges and the offshore flanges. Such flanges provide tough sealing with long life in hard service conditions. - Marine and Shipbuilding
The copper flanges made by Manibhadra Fitting are critical to industries in the UK that deal with the ocean as these flanges do not corrode easily in salt water. They are employed in cooling, fuel and bilge on boats and ships.
General Applications in UK :
- Residential Plumbing
Copper flanges are a common place in the UK domestic connections between water supply systems and heating systems. Manibhadra Fitting offers plumbing solutions that can be tailed quickly and which are durable. - District Heating Systems
Manibhadra Fitting copper flanges are used in the centralized heating system of towns and cities. Their power efficiency and their sealing ability cause them to be sustainable in terms of energy distribution. - Fire Protection Systems
These are also applied in sprinkle and fire suppression systems to make it work safely and reliably using these flanges. Manibhadra Fitting offers utmost safety to all the flanges in UK. - Public Infrastructure
The copper flanges produced by Manibhadra Fitting are applied in water supply lines, sewage treatment, and utility ring. They are advantageous relative to long-term performance in a public utility in terms of their corrosion resistance. - Healthcare and Educational buildings
Copper flanges represent the flanges applied in schools, universities, and UK hospitals. Manibhadra Fitting assists these industries through clean and long lasting piping products.
Copper Flanges Manufacturer, Stockist and Supplier in UK :- Advantages
Copper flanges by Manibhadra Fitting have many advantages because of which they are chosen by industry professionals and ordinary users of the flanges in the UK. These are flanges that are designed to be on the safe and durable side and even for a larger assorted offering of systems that have a variety of different environmental conditions.
- Corrosion Resistance
Manibhadra Fitting copper flanges are anti-rust and anti-corrosive especially in the presence of moisture or attack of chemicals, which prolongs the service life, minimizing the cost of the replacement. - Great Thermal output
They also have high thermal conductivity and are useful in the energy-efficient heating and cooling processes making them useful in HVAC as well as in district heating. - Power and Equilibrium
The flanges have been specially designed to have high pressure and high temperature tolerance and are stable and safe in critical applications. - Facility in Maintenance and Installation
Manibhadra Fitting has flanges made of copper which are manufactured with easy mobility designs that enable fast fitting, disassembling and has easy-low maintenance. - Multiplicity of Usage
Copper flanges present versatile, unparallelly flexibility and functionality to different industries, such as plumbing, HVAC, marine, and chemical industries within the UK.
