Detailed Copper Pipe Weight per Meter, Dimensions Chart in mm, kg PDF Online

Copper Tube and Pipe WEIGHT, DIMENSIONS CHART in mm, kg, 15mm copper pipe weight per meter

Manibhadra Fittings is a highly acclaimed Copper Pipe and Copper Tube Manufacturer in India. The following tables show standard sizes of copper tubes of three types (types K, type L, and type M), standard wall thickness, and standard weight per unit length of the tube. All dimensions are in accordance with ASTM B88. The tube wall thickness and tolerance are specified in millimeters. The mass of the tube per unit length is given in kilograms per meter.

Table of Contents

Weight Chart for EN 13348 Medical Grade / EN 1057 Copper Pipe (MGPS) for Central Medical Gas Pipeline Systems, Medical copper pipe weight per meter, copper pipe sizes in mm

EN 13348 medical grade copper pipes and EN 1057 medical grade copper pipes weight chart supplying the weight per meter information is accurate and very crucial in designing Central Medical Gas Pipeline Systems (MGPS). Such pipes are specifically produced according to sharp medical standards of purity, pressure, and safety levels.

Sr. No.	SIZE	Thickness	Length	Weight Per MTR	Weight Per 3 MTR	No. of Tubes Per Bundle	Weight Per Bundle
1	12MM	0.7	3 MTR	0.160	0.480	50	24
2	12MM	0.9	3 MTR	0.230	0.690	40	27.6
3	15MM	0.7	3 MTR	0.230	0.690	40	27.6
4	15MM	0.9	3 MTR	0.367	1.100	25	27.5
5	22MM	0.9	3 MTR	0.543	1.630	20	32.6
6	28MM	0.9	3 MTR	0.693	2.080	15	31.2
7	35MM	1.2	3 MTR	1.150	3.450	10	34.5
8	42MM	1.2	3 MTR	1.400	4.200	7	29.4
9	54MM	1.2	3 MTR	1.820	5.450	5	27.3
10	76MM	1.5	3 MTR	3.160	9.480	3	28.5
11	108MM	2.5	3 MTR	7.430	22.290	2	44.6

Copper Pipe Weight Chart for Medical Grade Copper Pipes as per EN 13348 in India/ copper pipe size chart

Medical copper pipes have a variable weight per meter depending on the outer size and thickness of walls to ensure an accurate plan in calculating loads and layout of the system in hospitals and health centers.

VRV/VRF Copper Hard Pipes for HVAC/R application, Standard Copper Tube sizes in mm, Weight Chart and Dimensions ASTM B68

Manibhadra Fittings is providing quality VRV/VRF Copper Hard Pipes to many HVAC/R applications, making it a manufacturer and supplier worth trusting. These pipes have been designed to conform to the specific requirements of ASTM B68 which guarantees their high reliability, accuracy and performance in refrigeration and air conditioning systems. In order to have a detailed look at our sizes, please refer to our weight chart and dimension for a smooth ordering process.

Sr no	Size (mm)	Size (Inches)	Temper	SWG	Thick (mm)	Length (Feets)	Weight per Meter	Internal Radius	Max Working Pressure in MPa	Bursting Pressure in MPa
1	6.4	1/4″	1/2 H	21 swg	0.8	10	0.126	2.4	45.6	83.3
2	9.4	3/8″	1/2 H	21 swg	0.8	10	0.196	3.95	27.7	50.6
3	12.7	1/2″	1/2 H	21 swg	0.8	10	0.268	5.55	19.7	36
4	15.9	5/8″	1/2	21 swg	0.8	10	0.339	7.15	15.3	28
5	15.9	5/8″	1/2 H	19 swg	1	10	0.419	6.95	19.7	36
6	19.1	3/4″	1/2 H	21 swg	0.8	10	0.411	8.75	12.5	22.9
7	22.2	7/8″	1/2 H	21 swg	0.8	10	0.481	10.3	10.6	19.4
8	25.4	1″	1/2 H	20 swg	0.88	10	0.606	11.82	10.2	18.6
9	28.6	1.1/8″	1/2 H	19 swg	1	10	0.776	13.3	10.3	18.8
10	31.8	1.1/4″	1/2 H	19 swg	1.1	10	0.949	14.8	10.2	18.6
11	34.9	1.3/8″	1/2 H	18 swg	1.21	10	1.145	16.24	10.2	18.6
12	38.1	1.1/2″	1/2 H	18 swg	1.32	10	1.364	17.73	10.2	18.6
13	41.3	1.5/8″	1/2 H	17 swg	1.43	10	1.602	19.22	10.2	18.6

Copper Hard Pipes/Tube Weight and Pressure Details as per ASTM B88 in India, copper pipe weight per meter

Copper Soft Pipe/Tube – VRV and Non-VRV – VRF and Non-VRF Copper 15 meter roll (50 Feet each) – Weight Chart below:

Soft copper pipes/tubes are vital for VRV, non-VRV, VRF, and non-VRF air conditioning systems. They ensure efficient flow of refrigerants. Sold in rolls of 15 meters (50 feet), the high-quality copper tubing is durable; a key concession to maintain thermal conductivity within HVAC applications.

SPECIFIC REQUIREMENT FOR VRF/VRV INSTALLATIONS – SOFT COIL FORM
Sr No	Size (mm)	Size (Inches)	Temper	Thick (mm)	Length (Feet)	Approx Weight per Coil	Internal Radius	Max Working Pressure (Mpa)	Bursting Pressure (Mpa)
1	6.4	1/4″	0 (Coil)	0.8	50	1.92	2.4	13.8	68.3
2	9.5	3/8″	0 (Coil)	0.8	50	2.98	3.95	8.4	41.5
3	12.7	1/2″	0 (Coil)	0.8	50	4.08	5.55	6	29.5
4	15.9	5/8″	0 (Coil)	1	50	6.38	6.95	5.9	29.5
5	19.1	3/4″	0 (Coil)	1	50	7.75	8.55	4.8	24

SPECIFIC REQUIREMENT FOR VRF/VRV INSTALLATIONS – SOFT COIL FORM / Copper Pipe Weight

LIGHT WEIGHT NON VRV/VRF INSTALLATIONS – SOFT COIL FORM
Sr No	Size (mm)	Size (Inches)	SWG	Thick (mm)	Length (Feet)	Approx Weight per Coil	Internal Radius	Max Working Pressure (Mpa)	Bursting Pressure (Mpa)
1	6.4	1/4″	23G	0.6	50	1.5	2.6	9.5	47.3
2	9.5	3/8″	23G	0.6	50	2.5	4.15	6	29.5
3	12.7	1/2″	22G	0.7	50	3.5	5.65	5.1	25.4
4	15.9	5/8″	22G	0.7	50	4.6	7.25	4.5	19.6
5	19.1	3/4″	21G	0.9	50	6.4	8.95	3.9	16.3

LIGHT WEIGHT NON VRV/VRF INSTALLATIONS – SOFT COIL FORM / Medical copper pipe weight per meter

Copper Pipe and Tubes – ASTM B88 Type K, ASTM B88 – Seamless Copper Water Tubes – Dimensions – Type K

The ASTM B88 Type K copper pipe or tubing standard presents thick-walled construction alongside excellent durability thus meeting requirements for underground water supply along with HVAC system components.

Nominal Size (inches)	Actual Outside Diameter			Tolerance on Outside Diameter				Wall Thickness				Weight
	Actual Outside Diameter			Annealed		Drawn		Nominal		Tolerance		Weight
	(inches)		(mm)	(inches)	(mm)	(inches)	(mm)	(inches)	(mm)	(inches)	(mm)	(lb/ft)	(Kg/m)
1/4	3/8	0.375	9.52	0.002	0.0508	0.001	0.0254	0.035	0.889	0.0035	0.0889	0.133	0.20
3/8	1/2	0.5	12.7	0.0025	0.0635	0.001	0.0254	0.049	1.24	0.005	0.127	0.269	0.40
1/2	5/8	0.625	15.9	0.0025	0.0635	0.001	0.0254	0.049	1.24	0.005	0.127	0.344	0.51
5/8	3/4	0.75	19	0.0025	0.0635	0.001	0.0254	0.049	1.24	0.005	0.127	0.418	0.62
3/4	7/8	0.875	22.2	0.003	0.0762	0.001	0.0254	0.065	1.65	0.006	0.152	0.641	0.95
1	1 1/8	1.125	28.6	0.0035	0.0889	0.0015	0.0381	0.065	1.65	0.006	0.152	0.837	1.25
1 1/4	1 3/8	1.375	34.9	0.004	0.102	0.0015	0.0381	0.065	1.65	0.006	0.152	1.04	1.55
1 1/2	1 5/8	1.625	41.3	0.0045	0.114	0.002	0.0508	0.072	1.83	0.007	0.178	1.36	2.02
2	2 1/8	2.125	54	0.005	0.127	0.002	0.0508	0.083	2.11	0.008	0.203	2.06	3.07
2 1/2	2 5/8	2.625	66.7	0.005	0.127	0.002	0.0508	0.095	2.41	0.01	0.254	2.92	4.35
3	3 1/8	3.125	79.4	0.005	0.127	0.002	0.0508	0.109	2.77	0.011	0.279	4	5.95
3 1/2	3 5/8	3.625	92.1	0.005	0.127	0.002	0.0508	0.12	3.05	0.012	0.305	5.12	7.62
4	4 1/8	4.125	105	0.005	0.127	0.002	0.0508	0.134	3.4	0.013	0.33	6.51	9.69
5	5 1/8	5.125	130	0.005	0.127	0.002	0.0508	0.16	4.06	0.016	0.406	9.67	14.39
6	6 1/8	6.125	156	0.005	0.127	0.002	0.0508	0.192	4.88	0.019	0.483	13.87	20.64

Copper Pipe and Tubes – ASTM B88 Type K, ASTM B88 – Seamless Copper Water Tubes – Dimensions – Type K, copper pipe size chart

Copper Pipe and Tubes – ASTM B88 Type K, ASTM B88 – Seamless Copper Water Tubes – Dimensions – Type K – Applications and Features

Application	– Domestic water supply – Service and distribution lines – Fire protection systems – Solar systems – Fuel & oil lines – HVAC systems – Compressed air – Oxygen – LPG gas – Snow melting systems – Steam systems – Vacuum systems
Fitting Options	– Sweat fittings – Compression fittings – Flare fittings
Types Available	– Hard type – Soft type
Special Note	– Outside diameter is 1/8 inch larger than standard size designation – Not allowed for natural gas distribution in the U.S. (due to odor additives, moisture, and solder cracking issues)

Copper Pipe and Tubes – ASTM B88 Type K, ASTM B88 – Seamless Copper Water Tubes – Dimensions – Type K – Applications and Features

Contact Us

ASTM B88 – Seamless Copper Water Tubes – Dimensions – Type L, Copper Tube and Pipe – ASTM B88 Type L, Medical copper pipe weight per meter

ASTM B88 Type L copper pipes and tubes are commonly used in medical gas pipeline systems because of their excellent durability and corrosion resistance. The weight of medical copper pipes per meter differs according to the diameter and wall thickness to ensure effective and safe gas flow in healthcare institutions.

Nominal Size	Actual Outside Diameter			Weight		Tolerance on Outside Diameter				Wall Thickness
Nominal Size	Actual Outside Diameter			Weight		Annealed		Drawn		Nominal		Tolerance
(inches)	(inches)	(inches)	(mm)	(lb/ft)	(kg/m)	(inches)	(mm)	(inches)	(mm)	(inches)	(mm)	(inches)	(mm)
1/4	3/8	0.375	9.52	0.126	0.187	0.002	0.0508	0.001	0.0254	0.03	0.762	0.003	0.0762
3/8	1/2	0.5	12.7	0.198	0.286	0.0025	0.0635	0.001	0.0254	0.035	0.889	0.004	0.102
1/2	5/8	0.625	15.9	0.285	0.424	0.0025	0.0635	0.001	0.0254	0.04	1.02	0.004	0.102
5/8	3/4	0.75	19	0.362	0.539	0.0025	0.0635	0.001	0.0254	0.042	1.07	0.004	0.102
3/4	7/8	0.875	22.2	0.455	0.678	0.003	0.0762	0.001	0.0254	0.045	1.14	0.004	0.102
1	1 1/8	1.125	28.6	0.655	0.974	0.0035	0.0889	0.0015	0.0381	0.05	1.27	0.005	0.127
1 1/4	1 3/8	1.375	34.9	0.884	1.315	0.004	0.102	0.0015	0.0381	0.055	1.4	0.006	0.152
1 1/2	1 5/8	1.625	41.3	1.14	1.697	0.0045	0.114	0.002	0.0508	0.06	1.52	0.006	0.152
2	2 1/8	2.125	54	1.75	2.602	0.005	0.127	0.002	0.0508	0.07	1.78	0.007	0.178
2 1/2	2 5/8	2.625	66.7	2.48	3.687	0.005	0.127	0.002	0.0508	0.08	2.03	0.008	0.203
3	3 1/8	3.125	79.4	3.33	4.954	0.005	0.127	0.002	0.0508	0.09	2.29	0.009	0.229
3 1/2	3 5/8	3.625	92.1	4.29	6.381	0.005	0.127	0.002	0.0508	0.1	2.54	0.01	0.254
4	4 1/8	4.125	105	5.38	8.007	0.005	0.127	0.002	0.0508	0.114	2.9	0.011	0.279
5	5 1/8	5.125	130	7.61	11.33	0.005	0.127	0.002	0.0508	0.125	3.18	0.012	0.305
6	6 1/8	6.125	156	10.2	15.18	0.005	0.127	0.002	0.0508	0.14	3.56	0.014	0.356

ASTM B88 – Seamless Copper Water Tubes – Dimensions – Type L, Copper Tube and Pipe – ASTM B88 Type L, Medical copper pipe weight per meter / copper pipe size chart

ASTM B88 – Seamless Copper Water Tubes Type L, Copper Tube and Pipe – ASTM B88 Type L – Applications and Features

Applications	– Domestic water supply – Service and distribution lines – Fire protection systems – Solar systems – Fuel & oil lines – HVAC systems – Compressed air – LPG gas – Snow melting systems – Vacuum systems
Fitting Options	– Sweat fittings – Compression fittings – Flare fittings
Types Available	– Hard type – Soft type

ASTM B88 – Seamless Copper Water Tubes Type L, Copper Tube and Pipe – ASTM B88 Type L – Applications and Features

Copper Seamless Pipe and Tubes – ASTM B88 Type M, Medical copper pipe weight per meter, ASTM B88 – Seamless Copper Water Tubes – Dimensions – Type M

ASTM B88 Type M copper pipes also come in a variety of outside diameters, along with wall thicknesses, based upon application. The sizes for the pipes may either be Imperial (inch) or Metric (millimeter).

Nominal Size	Actual Outside Diameter			Tolerance on Outside Diameter				Wall Thickness				Weight
Nominal Size	Actual Outside Diameter			Annealed		Drawn		Nominal		Tolerance		Weight
(inches)	(inches)	(inches)	(mm)	(inches)	(mm)	(inches)	(mm)	(inches)	(mm)	(inches)	(mm)	(lb/ft)	(mm)
1/4	3/8	0.375	9.52	0.002	0.0508	0.001	0.0254	–	–	–	–	0.106	0.158
3/8	1/2	0.5	12.7	0.0025	0.0635	0.001	0.0254	0.025	0.64	0.002	0.0508	0.144	0.214
1/2	5/8	0.625	15.9	0.0025	0.0635	0.001	0.0254	0.028	0.71	0.003	0.0762	0.203	0.302
5/8	3/4	0.75	19	0.0025	0.0635	0.001	0.0254	–	–	–	–	0.263	0.391
3/4	7/8	0.875	22.2	0.003	0.0762	0.001	0.0254	0.032	0.81	0.003	0.0762	0.328	0.488
1	1 1/8	1.125	28.6	0.0035	0.0889	0.0015	0.0381	0.035	0.89	0.004	0.102	0.464	0.691
1 1/4	1 3/8	1.375	34.9	0.004	0.102	0.0015	0.0381	0.042	1.07	0.004	0.102	0.681	1.013
1 1/2	1 5/8	1.625	41.3	0.0045	0.114	0.002	0.0508	0.049	1.24	0.005	0.127	0.94	1.399
2	2 1/8	2.125	54	0.005	0.127	0.002	0.0508	0.058	1.47	0.006	0.152	1.46	2.173
2 1/2	2 5/8	2.625	66.7	0.005	0.127	0.002	0.0508	0.065	1.65	0.006	0.152	2.03	3.021
3	3 1/8	3.125	79.4	0.005	0.127	0.002	0.0508	0.072	1.83	0.007	0.178	2.68	3.988
3 1/2	3 5/8	3.625	92.1	0.005	0.127	0.002	0.0508	0.083	2.11	0.008	0.203	3.58	5.328
4	4 1/8	4.125	105	0.005	0.127	0.002	0.0508	0.095	2.41	0.01	0.254	4.66	6.935
5	5 1/8	5.125	130	0.005	0.127	0.002	0.0508	0.109	2.77	0.011	0.279	6.66	9.911
6	6 1/8	6.125	156	0.005	0.127	0.002	0.0508	0.122	3.10	0.012	0.305	8.91	13.260

Copper Seamless Pipe and Tubes – ASTM B88 Type M, Medical copper pipe weight per meter, ASTM B88 – Seamless Copper Water Tubes – Dimensions – Type M / copper pipe size chart

Copper Seamless Pipe and Tubes – ASTM B88 Type M, Medical copper pipe weight per meter, ASTM B88 – Seamless Copper Water Tubes – Dimensions – Type M – Applications and Features

Applications	– Domestic water supply – Service and distribution lines – Fire protection systems – Solar systems – Fuel & oil lines – HVAC systems – Snow melting systems – Vacuum systems
Wall Thickness	– Thinner compared to Type K and Type L
Fitting Options	– Flare fittings
Types Available	– Hard type – Soft type

Copper Seamless Pipe and Tubes – ASTM B88 Type M, Medical copper pipe weight per meter, ASTM B88 – Seamless Copper Water Tubes – Dimensions – Type M – Applications and Features

ASTM B88 Copper Water Tube – Specification Details

1. Annealed Tube

Suitable for use with:
- Flared fittings
- Compression fittings
- Solder-type fittings (requires rounding and sizing of tube ends where needed)

2. Drawn Temper Tube

Suitable for use with solder-type fittings
Types A and B (drawn temper) can be used with certain types and sizes of compression fittings
Standard length: 20 ft (6.096 m)

3. General Specification (ASTM B88)

Covers seamless copper water tube suitable for:
- General plumbing applications
- Conveyance of fluids
- HVAC and similar installations
Compatible with joining methods:
- Solder
- Flared fittings
- Compression fittings

4. Application Considerations

Tube selection depends on:
- Internal and external fluid pressure
- Installation and service conditions
- Local regulatory requirements
- Means of joining or bending
